The steering system uses a closed-center valve, piston pump, and accumulator to maintain uniform response, even at varied engine speeds. If the engine stops, emergency steering remains functional. The truck’s drive system adapts to vehicle weight, slope, resistance, and other working conditions to guarantee top-level performance.

Parameters

• Net Weight- 105T
• Engine Model- Weichai WP17
• Gearbox Type –
• Capacity (Struck/Heaped)- 60/78m³
• Size- 11812*6900*6185mm
• Left/Right Hand Drive- Left/Right
• Total Power- ≥1400kW
• Displacement- 16.72L
• Maximum Torque- 3000NM
• Max. Gradeability- 30%
• Min. Turning Radius- 13200mm
• Number/Type of Cylinders- 8/V shape,turbocharged
• Lubrication System- Automatic lubrication system
• Automatic/Manual- Automatic
• Axle-
• Tyre- 33.00R51
• Load Weight- 136T
