Features.

Clever Hydraulics
Wire rope reeling can proceed at a faster rate since larger flows guarantee greater efficiency. A closed mode of independently regulated combined motions achieves greater stability when lifting and luffing are done simultaneously without vibration.

A Double Pump The Intelligent Flow Distribution System
With its efficient flow distribution, tiny impact shock, and fast reaction to coupled motions, the electro-hydraulic control system is energy-efficient and eco-friendly. Accurate supervision: Excellent performance inching, min. A single rope can move at 1.2 m/min and min steadily. The slewing sound speed is 0.1°/s, achieving a precise mm level lift. Slewing buffer control integrated: free swing technology, boost buffer, and sequential brakes for seamless start and stop.
Performance-enhancing chassis
To ensure great reliability, 200,000 cycling fatigue tests were conducted on the innovative structural frame.
System of Intelligent Control

Parameters

Operation

Counterweight – 8.5T

Max. Lifting Capacity – 50T

Max. Boom Length – 44m

Max. Jib Length – 16m

Max. Lifting Height – 60.5m

Max. Lifting Moment – 1600kN·m

Traveling

Available Districts – LHD countries

Engine Model (Emission Standard) – DF Cummins ISLe340 40 (Euro III)

Max. Gradeability – 45%

Max. Traveling Speed – 90km/h

Wheel Formula – 8×4×4

Request for quote: +971525384269

Price: AED1568000
