This machine is widely trusted in civil projects with efficient drilling, high borehole accuracy, and strong lifting performance. Its telescopic wide chassis and roller slewing bearing guarantee stability even in deep borehole conditions. The EFI engine ensures optimized performance with reduced fuel consumption. Reinforced mast and Kelly bar increase drilling capacity by 25%. A modern 10-inch HD control screen enhances operational convenience.

Parameters

Main Chassis

• Base Engine- Isuzu 6HK1
• Engine Power- 212/2000kW/rpm
• Emission Regulation- China Stage Ⅲ

Rotary Drive

• Rated Speed- 5~30rpm
• Rated Output Torque- 220kN·m

Pile

• Max. Pile Diameter- 1800mm
• Max. Pile Depth- 64/51m

Crowd System

• Crowd Force- 180kN
• Stroke- 4200mm
• Line Pull- 190kN

Overall Machine

• Overall Height- 21040mm
• Operating Weight- 65T
• Transport Width- 3210mm
• Transport Height- 3560mm

Main Winch

• Lifting Capacity- 220kN
• Max. Line Speed- 75m/min
• Rope Diameter- 28mm

Price: 2500000 AED

For More Information

Call us Now: +971 525384269
