The integrated slewing buffer system enhances operational safety and comfort with technologies such as boost buffer, sequential braking, and free swing control. These features work together to ensure that movements start and stop smoothly, avoiding sudden jolts or disruptions. The result is a controlled and stable lifting process, minimizing mechanical stress and improving overall handling during both start-up and shut-down operations.

Parameters

Operation

• Counterweight- 20.7 (standard) + 5 (optional)T
• Max. Lifting Capacity- 90T
• Max. Boom Length- 50m
• Max. Jib Length- 27m
• Max. Lifting Height- 77m
• Max. Lifting Moment- 3410kN·m

Traveling

• Available Districts- LHD countries
• Engine Model (Emission Standard)- DF CUMMINS ISLe375 30 (Euro Ⅲ )
• Max. Gradeability- 45%
• Max. Traveling Speed- 85km/h
• Wheel Formula- 8×4×4

Price: 1874000 AED
