Features

Power Optimization for Efficiency
Real-time power control ensures rapid and smooth composite actions with excellent fuel economy and low consumption.

Protective Step Drum
Single-layer step drum structure avoids wear and crushing, extending wire rope lifespan by 35%.

High-Performance Touchscreen
HD touchscreen with a 3ms refresh rate offers fluid animations and sharp visuals.

Parameters

Main Chassis

Base Engine: Isuzu 6WG1

Engine Power: 377/1800kW/rpm

Emission Regulation: China Stage Ⅲ

Rotary Drive

Rated Speed: 5~25rpm

Rated Output Torque: 405kN·m

Pile

Max. Pile Diameter: 2500/2200mm

Max. Pile Depth: 103/84m

Crowd System

Crowd Force: 350kN

Stroke: 13000mm

Line Pull: 400kN

Overall Machine

Overall Height: 27700mm

Operating Weight: 131T

Transport Width: 3500mm

Transport Height: 3660mm

Main Winch

Lifting Capacity: 400kN

Max. Line Speed: 75m/min

Rope Diameter: 36mm

Price: AED 3325000

Request for quote: +971525384269
