Features

 Superior Rock Drilling Force
This model, the largest in its class, offers impressive crowding force along with a heavy-duty reducer designed to resist impacts, maintaining consistent torque for drilling rock exceeding 60MPa.

Long-Lasting Durability
The structural components employ impact and fatigue resistance, and the Kelly bar’s single-layer wire rope winding minimizes friction between layers, extending wire rope lifespan by 35%.

Fuel-Efficient and Economical
Thanks to advanced power optimization control, the system distributes power efficiently and responds quickly, resulting in 10-15% less fuel consumption.

Parameters

Main Chassis

Base Engine: Isuzu 6WG1

Engine Power: 377/1800kW/rpm

Emission Regulation: China Stage Ⅲ

Rotary Drive

Rated Speed: 5～25rpm

Rated Output Torque: 405kN·m

Pile

Max. Pile Diameter: 2800mm

Max. Pile Depth: 103/84m

Crowd System

Crowd Force: 340kN

Stroke: 6000mm

Line Pull: 380kN

Overall Machine

Overall Height: 27700mm

Operating Weight: 131T

Transport Width: 3550mm

Transport Height: 3745mm

Main Winch

Lifting Capacity: 400kN

Max. Line Speed: 75m/min

Rope Diameter: 36mm

Price: AED 3342000

Request for quote: +971525384269
