Features

Strong and Stable Rock Drilling
This model leads its class with maximum crowding force and a heavy-duty, impact-resistant reducer to ensure steady torque output, drilling efficiently through rock exceeding 60MPa.

High Reliability Design
Structural parts use impact and fatigue resistance technology; the Kelly bar features single-layer wire rope winding to prevent wear and extend wire rope lifespan by 35%.

Energy-Conscious and Cost-Saving
Real-time power optimization control manages power allocation efficiently, providing quick response and lowering fuel consumption by 10-15%.

Parameters

Main Chassis

Base Engine: Isuzu 6WG1

Engine Power: 377/1800kW/rpm

Emission Regulation: China Stage Ⅲ

Rotary Drive

Rated Speed: 5～25rpm

Rated Output Torque: 405kN·m

Pile

Max. Pile Diameter: 2800mm

Max. Pile Depth: 103/84m

Crowd System

Crowd Force: 340kN

Stroke: 6000mm

Line Pull: 380kN

Overall Machine

Overall Height: 27700mm

Operating Weight: 131T

Transport Width: 3550mm

Transport Height: 3745mm

Main Winch

Lifting Capacity: 400kN

Max. Line Speed: 75m/min

Rope Diameter: 36mm

Price: AED 3342000

Request for quote: +971525384269
