Features

 Excellent Drilling Performance for Hard Rock
The largest model in its category guarantees high crowding force and stable torque output with a heavy-duty, impact-resistant reducer, capable of drilling rock over 60MPa.

Durability Through Advanced Design
The structure incorporates impact and fatigue-resistant technology, while the Kelly bar’s single-layer wire rope winding prevents abrasion, extending wire rope life by 35%.

Fuel-Efficient and Economical
The system’s power optimization control technology delivers real-time power distribution with rapid response, cutting fuel consumption by 10 to 15%.

Parameters

Main Chassis

Base Engine: Isuzu 6WG1

Engine Power: 377/1800kW/rpm

Emission Regulation: China Stage Ⅲ

Rotary Drive

Rated Speed: 5～25rpm

Rated Output Torque: 405kN·m

Pile

Max. Pile Diameter: 2800mm

Max. Pile Depth: 103/84m

Crowd System

Crowd Force: 340kN

Stroke: 6000mm

Line Pull: 380kN

Overall Machine

Overall Height: 27700mm

Operating Weight: 131T

Transport Width: 3550mm

Transport Height: 3745mm

Main Winch

Lifting Capacity: 400kN

Max. Line Speed: 75m/min

Rope Diameter: 36mm

Price: AED 3342000

Request for quote: +971525384269
