Features

High Efficiency, Low Fuel Cost

Performs exceptionally in deep borehole construction, ensuring quick lifting speeds and vertical precision.

Special Chassis for Stability
Designed with a telescopic wide base and large slewing bearing to support deep and stable drilling performance.

Smart Engine Tech
Imported EFI engine automatically adjusts power, delivering fast response and superior fuel efficiency.

Parameters

Main Chassis

Base Engine: ISUZU 6UZ1

Engine Power: 257/2000kW/rpm

Emission Regulation: China Stage III

Rotary Drive

Rated Speed: 5~32rpm

Rated Output Torque: 235kN·m

Pile

Max. Pile Diameter: 2000mm

Max. Pile Depth: 68/52m

Crowd System

Crowd Force: 210kN

Stroke: 5000mm

Line Pull: 270kN

Overall Machine

Overall Height: 22870mm

Operating Weight: 81T

Transport Width: 3540mm

Transport Height: 3660mm

Main Winch

Price: AED 1,900,000

Request for quote: +971525384269
