Features

High-Powered Performance
The engine, co-developed with top global manufacturers, complies fully with Tier III and IV emission standards. It delivers reliable, consistent power with excellent fuel efficiency and low consumption.

Extended Stroke Crowd System
Equipped with a 15-meter extra-long stroke, the system enables rapid crowd and lifting operations. It’s especially suitable for long casing applications in complex formations such as beaches, pebbles, and backfill.

Kelly Bar Position Monitoring
The system provides real-time visualization of the locking mechanism’s position when using an interlocking Kelly bar, helping to prevent operational errors and reduce the risk of accidental damage.

Parameters

Standard Mode

Crowd Force: 180kN

Stroke: 14300mm

Overall Height: 21040mm

Max. Pile Diameter: 1600mm

Max. Pile Depth: 59/47m

Operating Weight: 63T

Line Pull: 180kN

Rated Speed: 5~34rpm

Rated Output Torque: 190kN·m

Main Chassis

Base Engine: ISUZU 6HK1

Engine Power: 212/2000kW/rpm

Emission Regulation: China Stage III

Overall Machine

Transport Width: 3215mm

Transport Height: 3495mm

Main Winch

Lifting Capacity: 185kN

Max. Line Speed: 75m/min

Rope Diameter: 28mm

Price: AED 1925000

Request for quote: +971525384269
