Features

Fast & Stable Drilling
Designed for deep, narrow boreholes with efficient hoist speed and strong vertical precision.

Rotary Rig Chassis
Telescopic, wide-frame chassis and large slewing bearing provide reliable deep drilling support.

Energy-Saving Powertrain
Imported EFI engine delivers strong power while minimizing fuel use through real-time optimization.

Parameters

Main Chassis

Base Engine: ISUZU 6HK1

Engine Power: 212/2000kW/rpm

Emission Regulation: China Stage III

Rotary Drive

Rated Speed: 5~34rpm

Rated Output Torque: 190kN·m

Pile

Max. Pile Diameter: 1800mm

Max. Pile Depth: 59/47m

Crowd System

Crowd Force: 180kN

Stroke: 4200mm

Line Pull: 180kN

Overall Machine

Overall Height: 21040mm

Operating Weight: 63T

Transport Width: 3210mm

Transport Height: 3560mm

Main Winch

Lifting Capacity: 185kN

Max. Line Speed: 75m/min

Rope Diameter: 28mm

Price: AED 1362000

Request for quote: +971525384269
