Features

Oil and Gas Suspension
The enhanced front oil and gas suspension offers superior buffering and vibration control, significantly reducing impacts on the cab, frame, and other major components. This reduces mechanical failures, increases vehicle durability, and completely eliminates front plate spring breakage issues.

Full Hydraulic and Emergency Steering
The hydraulic steering system reduces the strain of traditional mechanical systems, especially in heavy-duty trucks. An emergency backup ensures reliable steering control in case of engine or pump failure.

Intelligent Electrical System

• The integrated SANY control unit features automated diagnostics for electrical issues.

• A 10-inch touchscreen supports GPS, a reversing camera, Bluetooth, and is fully compatible with smart mine management platforms.

Parameters

Automatic/Manual: Automatic

Axle: 35+55+55(t)

Capacity (Struck/Heaped): 50/61m³

Displacement: 16.72L

Engine Model: Weichai WP17G770E304

Left/Right Hand Drive: Left/Right

Load Weight: 90T

Lubrication System: Optional automatic lubrication

Max. Gradeability: >30%

Maximum Torque: 3000NM

Min. Turning Radius: 13000mm

Net Weight: 54T

Number/Type of Cylinders: 8/V shape,turbocharged

Size: 11165*5810*4850mm

Total Power: 925kW

Tyre: 18.00R33

Price: AED 1836000

Request for quote: +971525384269
