Features.

Practical and Adaptable
Tall verticality of the completed boreholes, high main hoist lifting up and down speed, small diameter and deep borehole construction, and great working efficiency are all examples of their widespread application in civil engineering.

A Unique Chassis
To ensure excellent stability when drilling deep boreholes, a telescopic huge widening chassis with a roller type large diameter slewing bearing is built for rotary drilling rigs.
economical and energy-efficient
solidly powered imported large displacement EFI engine that uses power optimization control technology, dynamically modifies power distribution, responds quickly, uses less gasoline, and uses less energy.

Parameters

Main Chassis

Base Engine – ISUZU 4HK1

Engine Power – 133/2000kW/rpm

Emission Regulation – China Stage III

Rotary Drive

Rated Speed – 6～45rpm

Rated Output Torque – 140kN·m

Pile

Max. Pile Diameter – 1300/1500mm

Max. Pile Depth – 45/36m

Crowd System

Crowd Force – 120kN

Stroke – 3700mm

Line Pull – 160kN

Overall Machine

Overall Height – 16490mm

Operating Weight – 37T

Transport Width – 2660/2550mm

Transport Height – 3435mm

Main Winch

Lifting Capacity – 160kN

Max. Line Speed – 80m/min

Rope Diameter – 24mm

Request for quote: +971525384269

Price: AED1,200,000
