Sinoboom AB10J – Lightweight Lift, Strong Capabilities
Weighing under 5 tons, the AB10J is transport-friendly but strong enough for rough terrain and city work. With 4WD, 40% gradeability, and a 250 kg platform capacity, it’s built to maximize efficiency while reducing downtime.

Highlights:

• Transport-Ready, Lightweight Build

• Stable and Safe Performance

• Easy Maintenance Features

Technical specification:

Reference Number- AMH269

Working hours- 0 hrs

Operating weight (kg)- 4,990 Kg

Engine Output- 18.2 kW

Max Number of Operators- 2

Working Height- 12.38 m

Platform Capacity- 250 kg

Telematics- Available

Max Horizontal Extension- 5.9 m

Power- Diesel

Drive × Steer- 4WD × 2WS

Turntable Rotation- 355 ° non-continuous

Platform Rotation- 160°

Gradeability- 40%

Features:

• 4WD x 2WS Proportional control

• Hydraulic platform leveling

• Tilt protection system

• Emergency lowering system

• Emergency stop system & All motion alarm

• Flashing beacon 355° non-continuous rotation

• Weighing system Anti-pinch device

• Foam-filled non-marking RT tires

• Two-speed travel motor

• Automatic engine shutdown in case of malfunction

• Swing-out engine tray

 —-Request for quote: +971525384269——–
