Features

Oil and Gas Suspension
The redesigned oil and gas suspension system in the front significantly enhances shock absorption and vibration control, lowering the impact on the frame and cab. This leads to fewer faults and eliminates front spring fractures, prolonging the truck’s operational lifespan.

Hydraulic and Emergency Steering System
The full hydraulic steering makes maneuvering easier for large trucks, while the emergency steering ensures functionality even if the engine stalls or the steering pump fails.

Advanced Electrical System

• Features SANY’s intelligent module for self-diagnosing and fixing electrical issues.

• A 10-inch touchscreen includes Bluetooth, a reverse camera, GPS, and connects with intelligent mining platforms.

Parameters

Automatic/Manual: Automatic

Axle: 35+55+55(t)

Capacity (Struck/Heaped): 50/61m³

Displacement: 16.72L

Engine Model: Weichai WP17G770E304

Left/Right Hand Drive: Left/Right

Load Weight: 90T

Lubrication System: Optional automatic lubrication

Max. Gradeability: >30%

Maximum Torque: 3000NM

Min. Turning Radius: 13000mm

Net Weight: 54T

Number/Type of Cylinders: 8/V shape,turbocharged

Size: 11165*5810*4850mm

Total Power: 925kW

Tyre: 18.00R33

Price: AED 1836000

Request for quote: +971525384269
