| Effective cut area | 1,600 x 3,100mm
(63″ x 122″) | 1,600 x 1,000mm
(63″ x 39.3″) |
|---|
| Head drive method | X.Y,Z.θ DC servo, special timing belt |
|---|
| Maximum speed | 50cm (19.6”)/s |
|---|
| Maximum acceleration | 0.5G |
|---|
| Static accuracy | Repeatability | ±0.15mm |
|---|
| Distance | ±0.1mm,or ±0.1% whichever is greater |
|---|
| Origin repeatability | ±0.15mm |
|---|
| Maximum cut depth | Router : 50mm (1.96″), Tangential cutter : 10mm (0.39″),
Reciprocating cutter : 20mm (0.78″) |
|---|
| Maximum media thickness | Router : 50mm (1.96″), Tangential cutter : 30mm (1.18″),
Reciprocating cutter : 20mm (0.78″) |
|---|
| Material clamp | Vacuum system with blower |
|---|
| Command | MGL-II c3 (MGL-IIc) |
|---|
| Interface | USB, RS-232C |
|---|
| Main unit power supply | 200V~240V, Single phase 50/60Hz Less than 6A |
|---|
| Dust collector power supply | AC100V-120V, Single phase 50/60Hz, Less than 15A
AC200V-240V, Single phase 50/60Hz, Less than 10A |
|---|
| Blower power supply | AC200V-240V, Single phase 50/60Hz,
Less than 30A per unit |
|---|
| Dimensions (WxDxH) | 2,250 x 4,120 x 1,320mm
(88.6″ x 162.2″ x 52.0″) | 2,250 x 1,860 x 1,320mm
(88.6″ x 73.3″ x 52.0″) |
|---|
