Features

Hydraulics with intelligence
Higher efficiency is ensured by larger flow, which permits wire rope reeling at a faster rate. Higher stability is achieved under simultaneous vibration-free lifting and luffing movements when shutted mode of independently controlled combined motions is used.

Two-Pump A System of Intelligent Flow Distribution
The electro-hydraulic control system achieves efficient flow distribution, is energy-efficient, ecologically benign, and responds quickly to combined motions and minor impact shocks. Accurate control: Outstanding performance inching, min. A single rope’s steady speed is 1.2 meters per minute. A precise lifting of mm level is achieved with a slewing sound speed of 0.1°/s. Integrated slewing buffer control: free swing technology, boost buffer, and sequential brakes for seamless starting and stopping.
High-performance chassis
High reliability was ensured by 200,000 cycling fatigue tests that validated the innovative structural structure.

Parameters

Operation

Counterweight – 7.5T

Max. Lifting Capacity – 55T

Max. Boom Length – 45m

Max. Jib Length – 16m

Max. Lifting Height – 61.5m

Max. Lifting Moment – 2009kN·m

Traveling

Available Districts – LHD area

Engine Model (Emission Standard) – DF Cummins ISLe340 30(Euro Ⅲ )

Max. Gradeability – 47%

Max. Traveling Speed – 90km/h

Wheel Formula – 8×4

Request for quote: +971525384269

Price: AED1200000
