Features

Small-sized Design
With its high degree of flexibility and quick transfer times, the three-axle cranes can reach a variety of urban or small job locations.

Two-Pump A System of Intelligent Flow Distribution
The electro-hydraulic control system achieves efficient flow distribution, is energy-efficient, ecologically benign, and responds quickly to combined motions and minor impact shocks. Accurate control: Outstanding performance inching, min. A single rope’s steady speed is 1.2 meters per minute. A precise lifting of mm level is achieved with a slewing sound speed of 0.1°/s. Integrated slewing buffer control: free swing technology, boost buffer, and sequential brakes for seamless starting and stopping.
High-performance chassis
High reliability was ensured by 200,000 cycling fatigue tests that validated the innovative structural structure.
Intelligent Control Mechanism

Parameters

Operation

Max. Lifting Capacity – 30T

Max. Lifting Height – 51m

Max. Lifting Moment – 1240kN·m

Max. Boom Length – 42.5m

Max. Jib Length – 8m

Counterweight – 6.4T

Traveling

Engine Model (Emission Standard) – Weichai WP7.300E31 (Euro III)

Max. Traveling Speed – 85km/h

Wheel Formula – 6×4

Max. Gradeability – 41%

Available Districts – RHD

Request for quote: +971525384269

Price: AED1465000
