Features:-

Adaptable and effective
In civil engineering, they are widely used due to their high operating efficiency, small diameter and deep borehole construction, tall verticality of completed boreholes, and high main hoist lifting up and down speed.

Particular Chassis
Rotating drilling rigs equipped with roller type large diameter slewing bearings and telescopic massive widening frames offer exceptional stability for drilling deep boreholes.
reliable, cost-effective, and competitively priced imported large displacement EFI engine with power optimization control technology, real-time power distribution adjustment, quick response time, enhanced fuel economy, and energy savings.

Parameters

Main Chassis

Base Engine – ISUZU 4JJ1

Engine Power – 84/2200kW/rpm

Emission Regulation – China Stage III

Rotary Drive

Rated Speed – 5~40rpm

Rated Output Torque – 70kN·m

Pile

Max. Pile Diameter – 1100mm

Max. Pile Depth – 27/20m

Crowd System

Crowd Force – 110kN

Stroke – 3000mm

Line Pull – 120kN

Overall Machine

Overall Height – 12765/8110mm

Operating Weight – 23T

Transport Width – 2700mm

Transport Height – 3410mm

Main Winch

Lifting Capacity – 90kN

Max. Line Speed – 80m/min

Rope Diameter – 20mm

Request for quote: +971525384269

Price: AED679000
