Qualities

Effective and Adaptable
Due to their high main hoist lifting up and down speed, tall verticality of the completed boreholes, high operating efficiency, and small diameter and deep borehole construction, they are widely utilized in civil engineering.

Unique Chassis
Roller type big diameter slewing bearings and a telescopic huge widening chassis for rotary drilling rigs ensure exceptional stability when digging deep boreholes.
Cost-effective and energy-efficient
solidly powered imported large displacement EFI engine that uses power optimization control technology, real-time power distribution adjustment, quick response time, increased fuel efficiency, and energy savings.

Parameters

Main Chassis

Base Engine – ISUZU 4HK1

Engine Power – 133/2000kW/rpm

Emission Regulation – China Stage III

Rotary Drive

Rated Speed – 6～45rpm

Rated Output Torque – 140kN·m

Pile

Max. Pile Diameter – 1300/1500mm

Max. Pile Depth – 45/36m

Crowd System

Crowd Force – 120kN

Stroke – 3700mm

Line Pull – 160kN

Overall Machine

Overall Height – 16490mm

Operating Weight – 37T

Transport Width – 2660/2550mm

Transport Height – 3435mm

Main Winch

Lifting Capacity – 160kN

Max. Line Speed – 80m/min

Rope Diameter – 24mm

Request for quote: +971525384269

Price: AED1,200,000
