A top choice for soil and rock layer construction, the SANY SR235-MIII Rotary Drilling Rig offers smooth compound motion control with adjustable torque and rotation speed. It adapts to various geological conditions and construction methods effortlessly. Its engines, developed alongside world-renowned suppliers, meet strict Tier IV/III emission standards while delivering stable and efficient power with low fuel consumption. With a 15m extra-long stroke, it supports fast crowding and pulling, ideal for long casing projects in beaches, pebbles, and backfill formations. The real-time location display for the inter-lock Kelly bar prevents accidental damage. Constant wire rope tension ensures longer service life. An HD touch screen with a 3ms refresh rate and fluid animations enhances usability, while regular lubrication maintains optimal performance.

Parameters

CFA Mode

• Crowd Force- /kN
• Stroke- 17060mm
• Overall Height- 29775mm
• Max. Pile Diameter- 1000mm
• Max. Pile Depth- 24m
• Operating Weight- 90T
• Line Pull- 770kN
• Rated Speed- 5~30rpm
• Rated Output Torque- 100~230kN·m

Standard Mode

• Crowd Force- 210kN
• Stroke- 15000mm
• Overall Height- 24050mm
• Max. Pile Diameter- 2000mm
• Max. Pile Depth- 73/56m
• Operating Weight- 86T
• Line Pull- 270kN
• Rated Speed- 5~30rpm
• Rated Output Torque- 235kN·m

Main Chassis

• Base Engine- 6UZ1
• Engine Power- 257/2000kW/rpm
• Emission Regulation- China Stage III

Low Headroom

• Crowd Force- 210kN
• Stroke- 4500mm
• Overall Height- 12135~13205mm
• Max. Pile Diameter- 2000mm
• Max. Pile Depth- 24m
• Operating Weight- 75T
• Line Pull- 270kN
• Rated Speed0- 5~30rpm
• Rated Output Torque- 235kN·m

Overall Machine

• Transport Width- 3550mm
• Transport Height- 3750mm

Main Winch

• Lifting Capacity- 235kN
• Max. Line Speed- 70m/min
• Rope Diameter- 32mm

Price: 260000 AED
