Astute Hydraulic
A larger flow guarantees greater efficiency, allowing wire rope reeling to proceed at a faster pace. Higher stability under simultaneous vibration-free lifting and luffing movements is achieved by the shuttered mode of independently regulated combined motions.
Dual Pump An intelligent system for distributing flow

Effective flow distribution is achieved by the electro-hydraulic control system, which is also energy-efficient, environmentally benign, and responsive to combined motions and minor contact shock. Control with precision: Outstanding inching performance, min. A single rope can move at a steady 1.2 m/min min. The accurate lifting of mm level is achieved with a slewing sound speed of 0.1°/s. Smooth start and stop thanks to integrated slewing buffer management, which combines free swing, sequential braking, and boost buffer technology.
High-performance chassis.
200,000 riding fatigue tests validated the innovative structural frame’s great reliability.

Parameters

Operation

Max. Lifting Capacity – 50T

Max. Lifting Height – 61m

Max. Lifting Moment – 2058kN·m

Max. Boom Length  44.5m

Max. Jib Length – 16m

Counterweight – 4.8T

Traveling

Engine Model (Emission Standard) = DF Cummins ISLe34030 (Euro Ⅲ)

Max. Traveling Speed – 85km/h

Wheel Formula – 8 × 4 × 4

Max. Gradeability – 45%

Available Districts – LHD area

Request for quote: +971525384269

Price: AED437000
