Features

Excellent Performance
Large core characteristics such strong crowd force and torque; quick main rope line speed to guarantee high drilling efficiency in hard soil layer; appropriate for large buildings, high-speed rail, overpasses, and other large hole foundation sectors.

Crowd for Full Stroke
Use a winch crowd system that exhibits a long stroke, rapid crowding, and a rotary drive display function. This system is appropriate for all types of casing construction, including backfill, pebble, and beach.
Economy and Energy Conservation
In order to distribute power in real-time with the smooth and quick response of composite action, power optimization control technology is used; additionally, it has low comprehensive fuel consumption and high fuel economy.

Parameters

Main Chassis

Base Engine – Isuzu 6WG1

Engine Power – 377/1800kW/rpm

Emission Regulation – China Stage Ⅲ

Rotary Drive

Rated Speed – 5~25rpm

Rated Output Torque – 405kN·m

Pile

Max. Pile Diameter – 2500/2200mm

Max. Pile Depth – 103/84m

Crowd System

Crowd Force – 350kN

Stroke – 13000mm

Line Pull – 400kN

Overall Machine

Overall Height – 27700mm

Operating Weight – 131T

Transport Width – 3500mm

Transport Height – 3660mm

Main Winch

Lifting Capacity – 400kN

Max. Line Speed – 75m/min

Rope Diameter – 36mm

Request for quote: +971525384269

Price: AED3325000
