Features

Performance-Driven Drilling Solution

Delivers speed, stability, and accuracy for small-diameter and deep borehole construction in modern civil projects.

Strong Base for Heavy Workloads
Equipped with a large slewing bearing and telescopic chassis for enhanced performance and drilling precision.

Smart and Economical Power Delivery
EFI engine with power optimization responds quickly to load changes while cutting fuel consumption.

Parameters

Main Chassis

Base Engine: ISUZU 6UZ1

Engine Power: 257/2000kW/rpm

Emission Regulation: China Stage III

Rotary Drive

Rated Speed: 5~32rpm

Rated Output Torque: 235kN·m

Pile

Max. Pile Diameter: 2000mm

Max. Pile Depth: 68/52m

Crowd System

Crowd Force: 210kN

Stroke: 5000mm

Line Pull: 270kN

Overall Machine

Overall Height: 22870mm

Operating Weight: 81T

Transport Width: 3540mm

Transport Height: 3660mm

Main Winch

Price: AED 1,900,000

Request for quote: +971525384269
