Features

Robust Power Output
Engines developed in collaboration with top-tier global suppliers comply with Tier III/IV emissions standards, ensuring steady, dependable performance with minimal fuel usage.

Extended Reach Crowd System
With a 15-meter long stroke, the system enables quick crowd and extraction operations, ideal for long casing work in challenging soils like beaches, pebbles, and backfilled ground.

Smart Kelly Position Display
The real-time location display of the locking system on the interlocking Kelly bar helps prevent misuse and accidental damage during drilling.

Parameters

Standard Mode

Crowd Force: 180kN

Stroke: 14300mm

Overall Height: 21040mm

Max. Pile Diameter: 1600mm

Max. Pile Depth: 59/47m

Operating Weight: 63T

Line Pull: 180kN

Rated Speed: 5~34rpm

Rated Output Torque: 190kN·m

Main Chassis

Base Engine: ISUZU 6HK1

Engine Power: 212/2000kW/rpm

Emission Regulation: China Stage III

Overall Machine

Transport Width: 3215mm

Transport Height: 3495mm

Main Winch

Lifting Capacity: 185kN

Max. Line Speed: 75m/min

Rope Diameter: 28mm

Price: AED 1925000

Request for quote: +971525384269
