Features

Oil and Gas Suspension
The new oil and gas front suspension system provides improved shock and vibration mitigation, significantly lowering impact forces on key vehicle components. This reduces failures and resolves the issue of spring fractures in the front axle.

Hydraulic Steering & Emergency Mode
Full hydraulic steering enables smoother handling, while the emergency feature ensures safe steering even after system failure.

Smart Electric Integration

• An onboard SANY module automatically detects and troubleshoots electrical faults.

• A 10″ digital display with GPS, Bluetooth, and camera support is integrated with intelligent mine control systems.

Parameters

Automatic/Manual: Automatic

Axle: 35+55+55(t)

Capacity (Struck/Heaped): 50/61m³

Displacement: 16.72L

Engine Model: Weichai WP17G770E304

Left/Right Hand Drive: Left/Right

Load Weight: 90T

Lubrication System: Optional automatic lubrication

Max. Gradeability: >30%

Maximum Torque: 3000NM

Min. Turning Radius: 13000mm

Net Weight: 54T

Number/Type of Cylinders: 8/V shape,turbocharged

Size: 11165*5810*4850mm

Total Power: 925kW

Tyre: 18.00R33

Price: AED 1836000

Request for quote: +971525384269
