characteristics

Astute Hydraulic
A larger flow guarantees greater efficiency, allowing wire rope reeling to proceed at a faster pace. Higher stability under simultaneous vibration-free lifting and luffing movements is achieved by the shuttered mode of independently regulated combined motions.

Dual Pump An intelligent system for distributing flow
Effective flow distribution is achieved by the electro-hydraulic control system, which is also energy-efficient, environmentally benign, and responsive to combined motions and minor contact shock. Control with precision: Outstanding inching performance, min. A single rope can move at a steady 1.2 m/min min. The accurate lifting of mm level is achieved with a slewing sound speed of 0.1°/s. Smooth start and stop thanks to integrated slewing buffer management, which combines free swing, sequential braking, and boost buffer technology.
High-performance chassis.
200,000 riding fatigue tests validated the innovative structural frame’s great reliability.

Parameters

Operation

Counterweight – 7.5T

Max. Lifting Capacity – 55T

Max. Boom Length – 45m

Max. Jib Length – 16m

Max. Lifting Height – 61.5m

Max. Lifting Moment – 2009kN·m

Traveling

Available Districts – LHD area

Engine Model (Emission Standard) – DF Cummins ISLe340 30(Euro Ⅲ )

Max. Gradeability – 47%

Max. Traveling Speed – 90km/h

Wheel Formula – 8×4

Request for quote: +971525384269

Price: AED1200000
