Qualities

High Effectiveness
It is appropriate for overpasses, high-speed rail, huge buildings, and other large hole foundation fields. Its large core parameters, such as strong torque and crowd force, and its fast line speed of main rope guarantee good drilling efficiency in hard soil layers.

Crowd with Full Stroke
Use a winch crowd system that is appropriate for all types of casing construction in the beach, pebble, and backfill formations. It has a long stroke, quick crowding, and a rotary drive display function.
Saving Money and Energy
With the smooth and quick response of composite action, power optimization control technology is used to distribute power in real-time. It also has low comprehensive fuel consumption and high fuel economy.

Parameters

Main Chassis

Base Engine – Isuzu 6WG1

Engine Power – 377/1800kW/rpm

Emission Regulation – China Stage Ⅲ

Rotary Drive

Rated Speed – 5~25rpm

Rated Output Torque – 405kN·m

Pile

Max. Pile Diameter – 2500/2200mm

Max. Pile Depth – 103/84m

Crowd System

Crowd Force – 350kN

Stroke – 13000mm

Line Pull – 400kN

Overall Machine

Overall Height – 27700mm

Operating Weight – 131T

Transport Width – 3500mm

Transport Height – 3660mm

Main Winch

Lifting Capacity – 400kN

Max. Line Speed – 75m/min

Rope Diameter – 36mm

Request for quote: +971525384269

Price: AED3325000
