Features

Adaptable and productive
They are widely used in civil engineering due to their high operational efficiency, building of deep and small diameter boreholes, tall verticality of completed boreholes, and high main hoist lifting up and down speed.

A Unique Chassis
With their telescopic massive widening chassis and roller type big diameter slewing bearings, rotary drilling rigs offer exceptional stability for drilling deep boreholes.
This is a stable, energy-efficient, and affordable imported large displacement EFI engine that features power optimization control technology, real-time power distribution modification, quick reaction time, enhanced fuel efficiency, and energy savings.

Parameters

Main Chassis

Base Engine – ISUZU 4JJ1

Engine Power – 84/2200kW/rpm

Emission Regulation – China Stage III

Rotary Drive

Rated Speed – 5~40rpm

Rated Output Torque – 70kN·m

Pile

Max. Pile Diameter – 1100mm

Max. Pile Depth – 27/20m

Crowd System

Crowd Force – 110kN

Stroke – 3000mm

Line Pull – 120kN

Overall Machine

Overall Height – 12765/8110mm

Operating Weight – 23T

Transport Width – 2700mm

Transport Height – 3410mm

Main Winch

Lifting Capacity – 90kN

Max. Line Speed – 80m/min

Rope Diameter – 20mm

Request for quote: +971525384269

Price: AED679000
