Features.

Exceptional Efficiency
excellent torque and crowd force are examples of big core characteristics. The main rope’s fast line speed ensures excellent drilling efficiency in hard soil layers, making it appropriate for huge structures, high-speed rail, overpasses, and other large hole foundation sectors.

Complete Stroke Group
Use a winch crowd system that can be used for all types of casing construction in backfill, pebble, and beach structures. It has a long stroke, quick crowding, and a rotary drive display feature.
Financial and Energy Efficiency
Power optimization control technology is used to distribute power in real-time with composite action’s smooth and quick reaction. It also has low overall fuel consumption and excellent fuel economy.

Parameters

Main Chassis

Base Engine – Isuzu 6WG1

Engine Power – 300/1800kW/rpm

Emission Regulation – China Stage Ⅲ

Rotary Drive

Rated Speed – 5~22rpm

Rated Output Torque – 400kN·m

Pile

Max. Pile Diameter – 2500/2200mm

Max. Pile Depth – 105/86m

Crowd System

Crowd Force – 350kN

Stroke – 9000/18000mm

Line Pull – 380kN

Overall Machine

Overall Height – 27105mm

Operating Weight – 137T

Transport Width – 3530mm

Transport Height – 3575mm

Main Winch

Lifting Capacity – 410kN

Max. Line Speed – 70m/min

Rope Diameter – 36mm

Request for quote: +971525384269

Price: AED3300000
