Designed for soil and rock construction tasks, the SANY SR235-MIII Rotary Drilling Rig provides seamless compound motion with adjustable torque and rotation to suit different geological and project requirements. It’s powered by engines developed in partnership with leading global suppliers, fully compliant with Tier IV/III emission regulations for reliable and low-consumption performance. The 15-meter extra-long stroke ensures quick crowding and pulling, perfect for long casing work in beaches and gravel formations. A real-time lock position display helps avoid damage during operation, and continuous wire rope tension prolongs its life. The intuitive HD touch screen with a 3ms refresh rate delivers smooth animations, while scheduled grease maintenance ensures smooth lubrication.

Parameters

CFA Mode

• Crowd Force- /kN
• Stroke- 17060mm
• Overall Height- 29775mm
• Max. Pile Diameter- 1000mm
• Max. Pile Depth- 24m
• Operating Weight- 90T
• Line Pull- 770kN
• Rated Speed- 5~30rpm
• Rated Output Torque- 100~230kN·m

Standard Mode

• Crowd Force- 210kN
• Stroke- 15000mm
• Overall Height- 24050mm
• Max. Pile Diameter- 2000mm
• Max. Pile Depth- 73/56m
• Operating Weight- 86T
• Line Pull- 270kN
• Rated Speed- 5~30rpm
• Rated Output Torque- 235kN·m

Main Chassis

• Base Engine- 6UZ1
• Engine Power- 257/2000kW/rpm
• Emission Regulation- China Stage III

Low Headroom

• Crowd Force- 210kN
• Stroke- 4500mm
• Overall Height- 12135~13205mm
• Max. Pile Diameter- 2000mm
• Max. Pile Depth- 24m
• Operating Weight- 75T
• Line Pull- 270kN
• Rated Speed0- 5~30rpm
• Rated Output Torque- 235kN·m

Overall Machine

• Transport Width- 3550mm
• Transport Height- 3750mm

Main Winch

• Lifting Capacity- 235kN
• Max. Line Speed- 70m/min
• Rope Diameter- 32mm

Price: 260000 AED

For More Information

Call us on: +971 525384269
