Features

Efficient and Flexible
They are widely used in civil engineering because of their high main hoist lifting up and down speed, tall verticality of the completed boreholes, high operating efficiency, and small diameter and deep borehole construction.

Distinct Chassis
For rotary drilling rigs, a telescopic enormous widening chassis and roller type great diameter slewing bearings provide outstanding stability for drilling deep boreholes.
Solidly powered, imported large displacement EFI engine that is economical and energy-efficient. It makes use of real-time power distribution modification, power optimization control technology, fast reaction times, improved fuel efficiency, and energy savings.

Parameters

Main Chassis

Base Engine – ISUZU 4JJ1

Engine Power – 84/2200kW/rpm

Emission Regulation – China Stage III

Rotary Drive

Rated Speed – 5~40rpm

Rated Output Torque – 70kN·m

Pile

Max. Pile Diameter – 1100mm

Max. Pile Depth – 27/20m

Crowd System

Crowd Force – 110kN

Stroke – 3000mm

Line Pull – 120kN

Overall Machine

Overall Height – 12765/8110mm

Operating Weight – 23T

Transport Width – 2700mm

Transport Height – 3410mm

Main Winch

Lifting Capacity – 90kN

Max. Line Speed – 80m/min

Rope Diameter – 20mm

Request for quote: +971525384269

Price: AED679000
