Features

The hydraulic system features advanced matching technology that keeps oil temperature approximately 5°C lower than comparable models. Each module operates independently, ensuring no cross-function interference.

Designed with an enhanced steering angle beyond industry norms, the system provides greater flexibility and smoother directional control, improving overall operational output.

A patented suspension cylinder reduces vibration acceleration by 20%, while the McPherson independent suspension design minimizes side-force impact, extending the life of both the cylinder and tires.

Parameters

Automatic/Manual: Automatic

Capacity (Struck/Heaped): 26/35m³

Displacement: 16.1L

Engine Model: Volvo TAD1643VE-B

Gearbox Type: Avitec H6620AR

Left/Right Hand Drive: Left/Right

Load Weight: 55T

Lubrication System: Optional automatic lubrication

Max. Gradeability: 30%

Maximum Torque: 3260NM

Min. Turning Radius: 9540mm

Net Weight: 40T

Number/Type of Cylinders: 6,straight type

Size: 9155x5400x4505mm

Total Power: 565kW

Tyre: 24.00R35/E4

Price: AED 1913000

Request for quote: +971525384269
