Features

Energy Efficiency and Cost Savings
Employs power optimization control technology for real-time power distribution, ensuring smooth and rapid composite operations. It also delivers excellent fuel efficiency with reduced overall fuel consumption.

Step Drum Design
Features a single-layer step drum structure that prevents crushing and wear, extending the wire rope’s lifespan by 35%.

Smart Upgrade
Equipped with an HD touchscreen that refreshes every 3 milliseconds, providing smooth animations and clear display.

Parameters

Main Chassis

Base Engine: Isuzu 6WG1

Engine Power: 377/1800kW/rpm

Emission Regulation: China Stage Ⅲ

Rotary Drive

Rated Speed: 5~25rpm

Rated Output Torque: 405kN·m

Pile

Max. Pile Diameter: 2500/2200mm

Max. Pile Depth: 103/84m

Crowd System

Crowd Force: 350kN

Stroke: 13000mm

Line Pull: 400kN

Overall Machine

Overall Height: 27700mm

Operating Weight: 131T

Transport Width: 3500mm

Transport Height: 3660mm

Main Winch

Lifting Capacity: 400kN

Max. Line Speed: 75m/min

Rope Diameter: 36mm

Price: AED 3325000

Request for quote: +971525384269
