Features

Powerful Drilling in Tough Rock
The heaviest model in this category delivers substantial crowding force, paired with a heavy-duty, impact-resistant reducer that ensures stable torque output. It’s highly capable of drilling rock harder than 60MPa.

Durable Structural Design
Featuring impact and fatigue resistance technologies, the Kelly bar uses single-layer wire rope winding to prevent internal wear, increasing wire rope life by 35%.

Efficient and Cost-Effective Operation
With power optimization control technology, the machine dynamically manages power in real time, providing quick response and reducing fuel consumption by 10-15%.

Parameters

Main Chassis

Base Engine: Isuzu 6WG1

Engine Power: 377/1800kW/rpm

Emission Regulation: China Stage Ⅲ

Rotary Drive

Rated Speed: 5～25rpm

Rated Output Torque: 405kN·m

Pile

Max. Pile Diameter: 2800mm

Max. Pile Depth: 103/84m

Crowd System

Crowd Force: 340kN

Stroke: 6000mm

Line Pull: 380kN

Overall Machine

Overall Height: 27700mm

Operating Weight: 131T

Transport Width: 3550mm

Transport Height: 3745mm

Main Winch

Lifting Capacity: 400kN

Max. Line Speed: 75m/min

Rope Diameter: 36mm

Price: AED 3342000

Request for quote: +971525384269
