Features

Deep Drilling with Precision and Power

Ideal for small-diameter, deep borehole tasks in civil engineering, delivering consistent verticality and efficient operation.

Reinforced Base Structure
Equipped with a specially designed telescopic chassis and large slewing bearing to ensure excellent drilling stability.

Smart Fuel Control
The EFI engine intelligently balances power output to reduce fuel use and support responsive operation.

Parameters

Main Chassis

Base Engine: ISUZU 6UZ1

Engine Power: 257/2000kW/rpm

Emission Regulation: China Stage III

Rotary Drive

Rated Speed: 5~32rpm

Rated Output Torque: 235kN·m

Pile

Max. Pile Diameter: 2000mm

Max. Pile Depth: 68/52m

Crowd System

Crowd Force: 210kN

Stroke: 5000mm

Line Pull: 270kN

Overall Machine

Overall Height: 22870mm

Operating Weight: 81T

Transport Width: 3540mm

Transport Height: 3660mm

Main Winch

Price: AED 1,900,000

Request for quote: +971525384269
