Specifications

Superior Efficiency
The most demanding applications use hydraulic and powertrain components that are strong, dependable, and powerful. Selectable operating modes maximise productivity by matching machine performance to the application.

Exceptionally Long Service Life
15 years of experience combined with SANY’s “three-in-one” design and test method for large excavators have allowed them to operate for more than 15,000 hours in mining conditions.
Exceptionally High Adaptability
independent, huge radiator, high-capacity multi-stage filtration system, and anti-corrosion coating.
Intelligent System Operation Interface Upgrade: Fashion technology’s intelligent operation interface is now easier to use and more convenient.
Reduced Use of Fuel
Up to 5% more operating efficiency and 10% more fuel economy are possible with optimised positive flow hydraulics.

Parameters

Arm Digging Force – 89.7kN

Bucket Capacity – 0.8m³

Bucket Digging Force – 109.4kN

Carrier Wheel on Each Side – /

Engine Displacement – 4.9L

Engine Model – MITSUBISHI 4M50

Engine Power – 118kW

Fuel Tank – 1240L

Hydraulic Tank – 239L

Operating Weight – 27.5T

Radiator – /L

Standard Boom – 6.9m

Standard Stick – 4.0m

Thrust Wheel on Each Side – /

Request for quote: +971525384269

Price: AED993000
