Equipped with independent hydraulic steering featuring a closed-center steering valve, a pressure-compensating piston pump, and an accumulator, this truck ensures smooth and consistent steering at all times. Even if engine power is lost, the accumulator provides emergency steering capability. Its drive system performance is influenced by factors such as total vehicle weight, road gradient, distance, rolling resistance, and engine output. The system adapts intelligently to match working conditions for peak efficiency.

Parameters

• Net Weight- 105T
• Engine Model- Weichai WP17
• Gearbox Type –
• Capacity (Struck/Heaped)- 60/78m³
• Size- 11812*6900*6185mm
• Left/Right Hand Drive- Left/Right
• Total Power- ≥1400kW
• Displacement- 16.72L
• Maximum Torque- 3000NM
• Max. Gradeability- 30%
• Min. Turning Radius- 13200mm
• Number/Type of Cylinders- 8/V shape,turbocharged
• Lubrication System- Automatic lubrication system
• Automatic/Manual- Automatic
• Axle-
• Tyre- 33.00R51
• Load Weight- 136T
