Sinoboom AB10J – Efficient, Transport-Friendly Boom Lift
At under 5 tons, the AB10J is compact yet powerful, handling uneven terrain with its tilt rating and oscillation function. Its 250 kg platform supports two workers and tools, while the HMI system simplifies troubleshooting.

Highlights:

• Lightweight, Compact Size

• Strong Rough Terrain Capabilities

• Fast Maintenance Solutions

Technical specification:

Reference Number- AMH269

Working hours- 0 hrs

Operating weight (kg)- 4,990 Kg

Engine Output- 18.2 kW

Max Number of Operators- 2

Working Height- 12.38 m

Platform Capacity- 250 kg

Telematics- Available

Max Horizontal Extension- 5.9 m

Power- Diesel

Drive × Steer- 4WD × 2WS

Turntable Rotation- 355 ° non-continuous

Platform Rotation- 160°

Gradeability- 40%

Features:

• 4WD x 2WS Proportional control

• Hydraulic platform leveling

• Tilt protection system

• Emergency lowering system

• Emergency stop system & All motion alarm

• Flashing beacon 355° non-continuous rotation

• Weighing system Anti-pinch device

• Foam-filled non-marking RT tires

• Two-speed travel motor

• Automatic engine shutdown in case of malfunction

• Swing-out engine tray

 —-Request for quote: +971525384269——–
