Featuring a closed-center steering valve, piston pump, and accumulator, the hydraulic steering system ensures smooth control regardless of speed. Even with engine failure, the accumulator powers emergency steering. Drive system output changes according to load, slope, resistance, and road length to achieve optimal productivity.

Parameters

• Net Weight- 105T
• Engine Model- Weichai WP17
• Gearbox Type –
• Capacity (Struck/Heaped)- 60/78m³
• Size- 11812*6900*6185mm
• Left/Right Hand Drive- Left/Right
• Total Power- ≥1400kW
• Displacement- 16.72L
• Maximum Torque- 3000NM
• Max. Gradeability- 30%
• Min. Turning Radius- 13200mm
• Number/Type of Cylinders- 8/V shape,turbocharged
• Lubrication System- Automatic lubrication system
• Automatic/Manual- Automatic
• Axle-
• Tyre- 33.00R51
• Load Weight- 136T
