Hydraulics with intelligence
Higher efficiency is ensured by larger flow, which permits wire rope reeling at a faster rate. Higher stability is achieved under simultaneous vibration-free lifting and luffing movements when shutted mode of independently controlled combined motions is used.
Two-Pump A System of Intelligent Flow Distribution

The electro-hydraulic control system achieves efficient flow distribution, is energy-efficient, ecologically benign, and responds quickly to combined motions and minor impact shocks. Accurate control: Outstanding performance inching, min. A single rope’s steady speed is 1.2 meters per minute. A precise lifting of mm level is achieved with a slewing sound speed of 0.1°/s. Integrated slewing buffer control: free swing technology, boost buffer, and sequential brakes for seamless starting and stopping.
High-performance chassis
High reliability was ensured by 200,000 cycling fatigue tests that validated the innovative structural structure.

Parameters

Clever Hydraulics
Wire rope reeling can proceed at a faster rate since larger flows guarantee greater efficiency. A closed mode of independently regulated combined motions achieves greater stability when lifting and luffing are done simultaneously without vibration.
A Double Pump The Intelligent Flow Distribution System

With its efficient flow distribution, tiny impact shock, and fast reaction to coupled motions, the electro-hydraulic control system is energy-efficient and eco-friendly. Accurate supervision: Excellent performance inching, min. A single rope can move at 1.2 m/min and min steadily. The slewing sound speed is 0.1°/s, achieving a precise mm level lift. Slewing buffer control integrated: free swing technology, boost buffer, and sequential brakes for seamless start and stop.
Performance-enhancing chassis
To ensure great reliability, 200,000 cycling fatigue tests were conducted on the innovative structural frame.

Operation

Max. Lifting Capacity – 50T

Max. Lifting Height – 61m

Max. Lifting Moment – 2058kN·m

Max. Boom Length  44.5m

Max. Jib Length – 16m

Counterweight – 4.8T

Traveling

Engine Model (Emission Standard) = DF Cummins ISLe34030 (Euro Ⅲ)

Max. Traveling Speed – 85km/h

Wheel Formula – 8 × 4 × 4

Max. Gradeability – 45%

Available Districts – LHD area

Request for quote: +971525384269

Price: AED437000
