The wide-view panoramic windshield and reduced blind zones enhance visibility and safety. Its strengthened articulation bearing provides reliable steering performance. With hydraulic matching, oil temperature is reduced by 5℃ for better endurance. Independent systems prevent interference, while a wider steering angle improves maneuverability. The patented suspension system lowers vibration by 20%, and McPherson suspension minimizes wear, extending both suspension and tire life.

Parameters

• Automatic/Manual- Automatic
• Capacity (Struck/Heaped)- 26/35m³
• Displacement- 16.1L
• Engine Model- Volvo TAD1643VE-B
• Gearbox Type- Avitec H6620AR
• Left/Right Hand Drive- Left/Right
• Load Weight- 55T
• Lubrication System- Optional automatic lubrication
• Max. Gradeability- 30%
• Maximum Torque- 3260NM
• Min. Turning Radius- 9540mm
• Net Weight- 40T
• Number/Type of Cylinders- 6,straight type
• Size- 9155x5400x4505mm
• Total Power- 565kW
• Tyre- 24.00R35/E4
