Features

Heavy-Duty Drilling Capability
The heaviest model in its class provides strong crowding force supported by an impact-resistant reducer to maintain stable torque, making it ideal for drilling hard rock layers above 60MPa.

Robust and Reliable Components
Built with impact and fatigue resistance in mind, the Kelly bar uses single-layer wire rope winding to avoid wear, prolonging the wire rope’s service life by 35%.

Cost-Effective and Energy Saving
Power optimization control technology allows real-time power management and rapid compound response, reducing fuel use by 10-15%.

Parameters

Main Chassis

Base Engine: Isuzu 6WG1

Engine Power: 377/1800kW/rpm

Emission Regulation: China Stage Ⅲ

Rotary Drive

Rated Speed: 5～25rpm

Rated Output Torque: 405kN·m

Pile

Max. Pile Diameter: 2800mm

Max. Pile Depth: 103/84m

Crowd System

Crowd Force: 340kN

Stroke: 6000mm

Line Pull: 380kN

Overall Machine

Overall Height: 27700mm

Operating Weight: 131T

Transport Width: 3550mm

Transport Height: 3745mm

Main Winch

Lifting Capacity: 400kN

Max. Line Speed: 75m/min

Rope Diameter: 36mm

Price: AED 3342000

Request for quote: +971525384269
