Features

Built for Efficiency
Ideal for civil engineering tasks requiring deep drilling with high speed and straight boreholes.

Durable Support System
Engineered rotary chassis with a wide base and large slewing bearing for superior ground stability.

Economical Engine Design
EFI engine adapts power output on the go, improving fuel efficiency and reducing energy waste.

Parameters

Main Chassis

Base Engine: ISUZU 6HK1

Engine Power: 212/2000kW/rpm

Emission Regulation: China Stage III

Rotary Drive

Rated Speed: 5~34rpm

Rated Output Torque: 190kN·m

Pile

Max. Pile Diameter: 1800mm

Max. Pile Depth: 59/47m

Crowd System

Crowd Force: 180kN

Stroke: 4200mm

Line Pull: 180kN

Overall Machine

Overall Height: 21040mm

Operating Weight: 63T

Transport Width: 3210mm

Transport Height: 3560mm

Main Winch

Lifting Capacity: 185kN

Max. Line Speed: 75m/min

Rope Diameter: 28mm

Price: AED 1362000

Request for quote: +971525384269
