Features

High Efficiency and Flexibility
Perfect for civil engineering sites requiring deep and narrow boreholes, offering fast lifting speed, accurate alignment, and efficient performance.

Robust Chassis Structure
Features a widened telescopic base and heavy-duty slewing bearing for enhanced stability during rotary drilling.

Fuel-Efficient Engine
Equipped with an imported EFI engine that adjusts power dynamically, ensuring lower fuel consumption and faster system response.

Parameters

Main Chassis

Base Engine: ISUZU 4HK1

Engine Power: 133/2000kW/rpm

Emission Regulation: China Stage III

Rotary Drive

Rated Speed: 6～45rpm

Rated Output Torque: 140kN·m

Pile

Max. Pile Diameter: 1300/1500mm

Max. Pile Depth: 45/36m

Crowd System

Crowd Force: 120kN

Stroke: 3700mm

Line Pull: 160kN

Overall Machine

Overall Height: 16490mm

Operating Weight: 37T

Transport Width: 2660/2550mm

Transport Height: 33435mm

Main Winch

Lifting Capacity: 160kN

Max. Line Speed: 80m/min

Rope Diameter: 24mm

Price: AED 1,200,000

Request for quote: +971525384269
