Features

Flexible and Accurate
Handles small-diameter deep boreholes with precision, high lifting speed, and work efficiency.

Reinforced Chassis System
Widened, telescopic design and heavy-duty slewing bearing ensure structural stability.

Eco-Smart Engine
EFI technology ensures fast performance with better fuel control and lower energy consumption.

Parameters

Main Chassis

Base Engine: ISUZU 6HK1

Engine Power: 212/2000kW/rpm

Emission Regulation: China Stage III

Rotary Drive

Rated Speed: 5~34rpm

Rated Output Torque: 190kN·m

Pile

Max. Pile Diameter: 1800mm

Max. Pile Depth: 59/47m

Crowd System

Crowd Force: 180kN

Stroke: 4200mm

Line Pull: 180kN

Overall Machine

Overall Height: 21040mm

Operating Weight: 63T

Transport Width: 3210mm

Transport Height: 3560mm

Main Winch

Lifting Capacity: 185kN

Max. Line Speed: 75m/min

Rope Diameter: 28mm

Price: AED 1362000

Request for quote: +971525384269
