Features

Oil and Gas Suspension
Enhanced suspension with oil and gas technology improves front-end shock absorption and vibration control. This helps minimize frame and cab wear, extend the vehicle’s life, and resolve front plate spring breakage.

Full Hydraulic Steering with Emergency Backup
Hydraulic steering replaces traditional manual systems, making operation easier. Emergency mode provides safe control during engine or pump failure.

Intelligent Electronics System

• SANY’s electrical module can detect and resolve system errors automatically.

• Includes a 10” screen with Bluetooth, rear camera, GPS, and mine system compatibility.

Parameters

Automatic/Manual: Automatic

Axle: 35+55+55(t)

Capacity (Struck/Heaped): 50/61m³

Displacement: 16.72L

Engine Model: Weichai WP17G770E304

Left/Right Hand Drive: Left/Right

Load Weight: 90T

Lubrication System: Optional automatic lubrication

Max. Gradeability: >30%

Maximum Torque: 3000NM

Min. Turning Radius: 13000mm

Net Weight: 54T

Number/Type of Cylinders: 8/V shape,turbocharged

Size: 11165*5810*4850mm

Total Power: 925kW

Tyre: 18.00R33

Price: AED 1836000

Request for quote: +971525384269
