Features

Suspension: Variable damping oil-gas suspension cushions road impacts effectively, enhancing ride comfort in harsh environments.
Cab: Safety-certified cab with rollover protection, ergonomic adjustments, and noise reduction below 78 dB(A) for operator ease.
Frame: Engineered from strong steel with cast parts to minimize stress and maximize the frame’s lifespan.

Parameters

Net Weight: 34T

Engine Model: Weichai WP13G530E310

Gearbox Type: AT

Capacity (Struck/Heaped): 20/25.5m³

Size: 11500*3500*4100mm

Left/Right Hand Drive: Left/Right

Total Power: 390kW

Displacement: 12.54L

Maximum Torque: 2300NM

Max. Gradeability: 40%

Min. Turning Radius: 8900mm

Number/Type of Cylinders: 6,straight type

Lubrication System: Optional automatic lubrication

Automatic/Manual: Automatic

Axle: Kessler

Tyre: 29.5R25

Load Weight: 41T

Price: AED 2459000

Request for quote: +971525384269
