characteristics

Exceptional Performance
Large core characteristics such crowd force and high torque; rapid main rope line speed to guarantee high drilling efficiency in hard soil layer; appropriate for large buildings, high-speed rail, overpass, and other large hole foundation sectors.

Whole Stroke Group
Use a winch crowd system that can be used for all types of casing construction in backfill, pebble, and beach formations. It has a long stroke, quick crowding, and a rotary drive display feature.
Saving Money and Energy Efficiency
In addition to having a low overall fuel consumption and excellent fuel efficiency, power optimization control technology is used to distribute power in real-time with the composite action’s smooth and quick response.

Parameters

Main Chassis

Base Engine – Isuzu 6WG1

Engine Power – 377/1800kW/rpm

Emission Regulation – China Stage Ⅲ

Rotary Drive

Rated Speed – 5~25rpm

Rated Output Torque – 405kN·m

Pile

Max. Pile Diameter – 2500/2200mm

Max. Pile Depth – 103/84m

Crowd System

Crowd Force – 350kN

Stroke – 13000mm

Line Pull – 400kN

Overall Machine

Overall Height – 27700mm

Operating Weight – 131T

Transport Width – 3500mm

Transport Height – 3660mm

Main Winch

Lifting Capacity – 400kN

Max. Line Speed – 75m/min

Rope Diameter – 36mm

Request for quote: +971525384269

Price: AED3325000
